project description
Texas
Instruments is planning on introducing a new revision of the DRV8412
which will interface with a motor control card through a DIMM100 slot.
The DRV8412 is a dual full bridge pulse-width modulation (PWM) motor
driver. The presence of a variety of control cards, driven by a variety
of Texas Instruments microcontrollers and digital signal processors,
will aid in the introduction of the DRV8412 Revision F to the market.The use of high-end MSP430s, a family of low-power mixed-signal 16-bit microcontrollers, and C2000s, a family of high performance 32-bit microprocessors, to drive a DC motor allows more for robust control of motor speed and torque, in the presence of dynamic loads. Currently, Texas Instruments has a designed a C2000 control card with software-implemented motor control; our design team has been tasked with the design and fabrication of a MSP430 control card. This MSP430 control card must exactly meet the specifications of the C2000 control card.
